Fasteners & Joints: Overview & Selection Guide

A design drawing calls for a rigid connection between two components. Which fastener or joint type actually fits, though, depends on more than just the load. A screw, a pin, a weld, and a press fit all solve the same basic task in completely different ways. Understanding the system behind them means picking the right element faster, and avoiding costly missteps in procurement.

In brief: Fasteners and joints fall into three groups based on their working principle: form-fit (pins, keys, wedges), force-fit (screws, clamped joints, press fits), and material-fit (welding, brazing, adhesive bonding). Cutting across that is the distinction between detachable and permanent joints, which matters for maintenance and disassembly.

What are fasteners and joints?

Fasteners and joints are components or processes that mechanically connect two or more workpieces. They range from simple standardized parts like screws and nuts to joining processes like welding or bonding. In the latter case, no separate component acts as the connecting element.

In procurement practice, the choice of fastener or joint often gets left entirely to design engineering, without bringing in the procurement side. Yet standardized parts like screws differ substantially in availability and lead time from custom solutions like bespoke welded assemblies. Bringing both perspectives together early avoids delays that would otherwise only surface at incoming goods inspection.

How are fasteners and joints classified?

The most common classification distinguishes three working principles by which a joint transfers force between components. This grouping follows the same logic used in the German DIN 8593 standards series, which categorizes joining processes by connection type.

What are form-fit connections?

Form-fit connections transfer forces through the geometric shape of the parts, independent of friction or material bonding. A classic example is a shaft-hub connection via a key, where a groove in both the shaft and hub transfers torque through interlocking geometry. Pins, dowels, and wedges also belong to this group.

What this fastener type buys you is high load capacity perpendicular to the joining direction. What it costs you: form-fit connections usually need precisely matched machining, which raises manufacturing cost.

What are force-fit connections?

Force-fit connections transfer forces through friction generated by an applied clamping force. Bolted joints are by far the most common example. The screw's preload presses the parts together, and the actual force transfer happens through the resulting friction at the contact surfaces.

Clamped joints and press fits also belong to this group. On the plus side, this fastener type makes bolted joints easy to undo. The trade-off: the transferable force is limited by maximum friction and depends heavily on surface condition.

What are material-fit connections?

Material-fit connections form through a molecular bond of the material itself, as in welding, brazing, or adhesive bonding. Unlike form-fit and force-fit connections, there's no separate fastening component in the strict sense here, the joint itself becomes part of the material.

Where this fastening approach shines is high, even force transfer without added component weight. Where it falls short: material-fit connections are fundamentally permanent. Disassembly either destroys the joint or the components themselves.

What's the difference between detachable and permanent joints?

Cutting across the classification by working principle is the question of whether a joint can be undone without damage. This distinction is often more important for maintenance, repair, and recycling than the working principle itself.

Riveted joints are form-fit, but count as permanent, since undoing them destroys the rivet. Press fits with high interference can technically be separated, but usually only with effort that rules out reusing the parts.

How do you choose the right fastener or joint?

In our procurement projects, we specifically ask during part specification whether a joint will need to be undone later in the product's lifecycle, for maintenance or repair. Design engineers often think first about mechanical load and only afterward about disassembly. That leads to expensive rework on series products with planned maintenance.

Four criteria help with the selection: the magnitude and direction of the force to be transferred, whether later disassembly is needed, the manufacturing capability available at the supplier, and the operating environment. Moisture, temperature cycling, or aggressive media influence both the choice of working principle and the surface treatment needed, such as galvanizing for screws used outdoors. If you're sourcing series parts with high volume requirements, it's also worth checking whether the chosen fastener is available as a standard part or requires a custom solution.

How do the three working principles differ in sourcing and cost?

Beyond pure mechanics, procurement effort often decides the choice, not just technical suitability.

In procurement, the effort behind material-fit joints is regularly underestimated, since no additional component shows up on the bill of materials. In reality, weld quality depends heavily on the shop doing the work, not on an interchangeable catalog part. Anyone sourcing material-fit joints from the Far East should check the manufacturer's welding qualification just as closely as they'd check dimensional accuracy for form-fit or force-fit standard parts.

What standards govern fasteners and joints?

Several standards interlock, depending on the working principle and tolerance requirement a given fastener brings with it.

The working-principle classification itself traces back to the categorization of joining processes, as documented in the article on manufacturing joining technology).

Frequently Asked Questions

What's the difference between form-fit and force-fit?

Form-fit connections transfer forces through the geometric shape of the parts, independent of friction. Force-fit connections, by contrast, transfer forces through friction generated by an applied clamping force, as in a tightened screw.

Is a bolted joint detachable or permanent?

A bolted joint is detachable. It can be disassembled and reassembled any number of times, as long as the screw and thread aren't damaged. That sets it apart from permanent joints like rivets or welds.

Which fastener suits high-volume production?

High-volume production usually favors standardized force-fit or form-fit fasteners like screws or pins, since they're available as catalog parts. Material-fit joints like welding, by contrast, typically require additional manufacturing effort per part.

Can a form-fit connection still be permanent?

Yes. A riveted joint is the classic example: it transfers force through form-fit, but counts as permanent, since the rivet destroys itself when undone. Working principle and detachability are two independent properties. They don't automatically follow from the same classification.

Conclusion: the right classification makes selection easier

Classifying fasteners and joints by working principle and by whether they're detachable makes selection noticeably faster. It beats a purely intuitive decision for a new part every time. Taken together, both dimensions immediately show which fasteners and joints are realistically on the table for the application at hand.
