Electrogalvanizing vs. hot-dip galvanizing

Corrosion protection is a decisive factor in industrial production when it comes to the quality, service life, and cost-effectiveness of components. But when is electrogalvanizing the right choice, and when is hot-dip galvanizing?

Particularly in the case of steel and steel alloys, the question of whether electrogalvanizing or hot-dip galvanizing is the right process arises early on in the procurement and production process. Both pursue the same goal of protecting against corrosion, but differ significantly in terms of process, properties, and areas of application. It is therefore crucial for purchasers, logisticians, and companies that manufacture products to be aware of the differences.

Why galvanizing is indispensable in industrial production

Steel is a versatile material that is mechanically resilient and economically attractive. However, without additional protection, it is sensitive to moisture and oxygen. Corrosion can impair the stability of components, increase maintenance costs, and, in the worst case, lead to safety-related failures.

Galvanization not only protects steel as a physical barrier, but also has an electrochemical effect. The applied zinc is less noble than steel and is attacked first in the event of corrosion. This keeps the steel itself intact for longer, which is particularly important for components with a long service life.

The galvanizing process chosen not only influences corrosion protection, but also dimensional accuracy, appearance, further processing, and cost structure.

What is electrogalvanizing?

Electrogalvanizing, often referred to as galvanizing, is an electrochemical process. The steel component is immersed in an electrolyte bath and an electric current is applied. The electric current causes zinc ions to deposit evenly on the surface of the workpiece. Electrogalvanizing is often used in combination with additional passivation or sealing processes to further improve corrosion protection.

Typical characteristics of this process are:

• Very thin zinc layers (usually 5–25 micrometers)

• An even and smooth surface

• High dimensional accuracy

Advantages of electrogalvanizing

Galvanization offers particular advantages where precision and appearance play a key role:

• High dimensional accuracy: The thin coating allows tight tolerances to be maintained – ideal for components that require a precise fit.

• Very smooth surface: Visually appealing and well suited for visible components.

• Good further processing: Coated parts are easy to assemble, screw together, or paint.

• Suitable for small and delicate components: For example, screws, nuts, or precision parts.

Limitations of electrogalvanizing

Despite its advantages, electrogalvanizing is not suitable for every application. The thin zinc layer offers only limited protection against constant moisture or aggressive environments. In outdoor areas or in cases of heavy mechanical stress, electrogalvanizing quickly reaches its limits.

What is hot-dip galvanization?

Hot-dip galvanizing is a thermal immersion process. Steel components are immersed in a bath of liquid zinc at a temperature of around 450 °C. During this process, a metallurgical bond is formed between the steel and the zinc. The result is hot-dip galvanized steel, which is particularly resistant to environmental influences. Typical products that are permanently hot-dip galvanized include railings, fences, and steel beams in outdoor areas.

Characteristic features of hot-dip galvanizing are

• Significantly thicker zinc layers (usually 50–150 micrometers)

• Very robust, durable corrosion protection

• Typical, slightly rough surface

Advantages of hot-dip galvanizing

Hot-dip galvanizing is particularly advantageous where components are used long-term and under demanding conditions:

• Very high corrosion protection: Even in rain, snow, UV radiation, or industrial atmospheres.

• Long service life: Depending on the environment, several decades without additional protection.

• High mechanical strength: The thick zinc layer is resistant to impact and abrasion.

• Complete coating: Even edges, cavities, and hard-to-reach areas are protected.

Limitations of hot-dip galvanizing

Despite its very high corrosion protection, hot-dip galvanizing is not suitable for every application. The comparatively thick zinc coating can affect dimensional stability and is therefore only suitable for use to a limited extent on components with tight tolerances. In addition, hot-dip galvanized steel usually has a rougher, less uniform surface, which can be disadvantageous for visible components or components with high visual requirements.

6 Galvanizing aspects in direct comparison

1. Corrosion protection

Hot-dip galvanizing offers significantly higher corrosion protection than electrogalvanizing and is particularly suitable for long-term use in demanding environmental conditions.

2. Coating thickness

While electrogalvanizing uses very thin zinc coatings, hot-dip galvanizing produces significantly thicker protective coatings.

3. Surface

Electrogalvanized components are characterized by a smooth, uniform, and visually appealing surface, while hot-dip galvanized surfaces are more robust but also rougher.

4. Dimensional stability

Electrogalvanizing offers clear advantages for components with tight tolerances, as the thin coating has virtually no effect on dimensional stability.

5. Service life

Hot-dip galvanizing achieves a significantly longer service life than electrogalvanizing, especially in outdoor applications.

6. Costs

Electrogalvanizing is generally more cost-effective for small, precision components, while hot-dip galvanizing is particularly economical for durable, low-maintenance structures.

When is electrogalvanizing suitable?

Electrogalvanizing is particularly suitable for components where precision, dimensional accuracy, and a uniform surface finish are paramount. Typical areas of application are fasteners such as screws, nuts, or springs, as well as precision components in mechanical engineering and equipment manufacturing. Since the zinc layer is applied very thinly, tight fits are maintained, making the process ideal for components that need to be assembled or further processed with precision.

Electrogalvanizing is also a proven solution for products that are mainly used indoors or have to meet particularly high visual requirements. It is widely used in the series production of small and medium quantities, as it enables consistent quality and economical implementation.

When is hot-dip galvanizing the better choice?

Hot-dip galvanizing is primarily used where components are exposed to high mechanical and climatic stresses over long periods of time. Hot-dip galvanized steel is often used outdoors, for example for steel girders, railings, masts, or structures in construction and infrastructure. Hot-dip galvanizing also offers reliable protection in mechanical and plant engineering where components must function with low maintenance over many years.

Hot-dip galvanizing demonstrates its strengths wherever regular maintenance is only possible at great expense or is not economically viable. Its high protective effect and long service life make it the preferred choice for robust structures subject to high mechanical stress.

Which type of galvanization is right for your product?

The decision between electrogalvanizing and hot-dip galvanizing should always be made based on the application. Key questions to consider are:

• Where will the component be used, indoors or outdoors?

• What is the expected service life?

• What mechanical stresses will it be subjected to?

• How important are dimensional accuracy and appearance?

• Are there any relevant standards or customer specifications?

Clear specifications are crucial, especially in international sourcing. Misunderstandings regarding galvanization often lead to quality problems, rework, or complaints.
